3.91
Good Display
die cast aluminum
RGB
500*1000mm
1 year
3.91
Kinglight
| Quantity: | |
|---|---|
Product Description
LED Display--Software Support
Software support is an important component of LED displays, providing convenient content editing, scheduling, and monitoring functions. Common software support includes Content Management Systems (CMS) and remote control software.
Content Management System (CMS)
CMS is software specifically designed for LED displays, offering a graphical interface and a range of features that allow users to easily create, edit, and manage display content. Through CMS, users can upload, adjust, and arrange multimedia content, including images, videos, and text. CMS also supports functions such as multi-screen synchronization, scheduled playback, real-time monitoring, and fault alerts, facilitating centralized management of the displays.
Remote control software
Remote control software for LED displays allows users to remotely manage and control the displays through a network. With remote control software, users can monitor the status of the displays in real-time, adjust parameter settings, upload content, and schedule playback plans. This enables users to conveniently manage LED displays located in different locations, improving efficiency and convenience.
In summary
LED displays offer multiple signal interfaces such as HDMI, DVI, VGA, etc., to ensure compatibility with various input sources. Control methods can be achieved through physical buttons, remote controls, or software control to meet the operational needs of different users. Additionally, accompanying software support such as Content Management Systems (CMS) and remote control software allows users to easily perform content editing, scheduling, and monitoring, enhancing management efficiency and convenience.
Product Advantage
The advantages and features of our LED rental screen products
Programmability
LED displays can achieve various display effects and interactive functions through software control and programming. This allows LED displays to be updated and customized according to specific needs, providing a more flexible and personalized display experience.
Dust and waterproof performance
LED displays typically have dust and waterproof capabilities, allowing them to be used in harsh environmental conditions. This makes LED displays suitable for outdoor billboards, sports venues, and other occasions that require resistance to dust and water.
High reliability
LED displays adopt a modular design, meaning that even if one module fails, the other modules can still function properly, without affecting the overall use of the screen. This enhances the reliability and maintainability of LED displays.
Remote control and management
LED displays can be remotely controlled and managed through a network, enabling functions such as content updates, brightness adjustment, and fault detection. This facilitates the operation and maintenance of LED displays, saving labor and time costs.
Technical Parameters
Outdoor rental led display Parameter
| Pixel Pitch(mm) | 2.604mm | 2.976mm | 3.91mm | 4.81 mm |
| LED Spec | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Apolication | Outdoor | Outdoor | Outdoor | Outdoor |
| Pixel Density(dot/m²) | 147456 dots | 112896 dots | 65536 dots | 43264 dots |
| Module Size/mm | 250×250 | 250×250 | 250×250 | 250×250 |
| Module Resolution | 96X96 dots | 84X84 dots | 64X64 dots | 52X52 dots |
| Module Weigh | 0.5kg | 0.5kg | 0.5kg | 0.5kg |
| Scan | 1/32S | 1/28S | 1/16S | 1/13S |
| Cabinet Size/mm | 500X500mm | 500X500mm 500X1000mm | 500X500mm 500X1000mm | 500X500mm 500X1000mm |
| Cabinet Resolution | 192×192 dots | 168×168 dots 168×336 dots | 128×128 dots 128×256 dots | 104x104 dots 104×208 dots |
| Cabinet Weight | 8.5 kg 15kg | 8.5 kg 15kg | 8.5 kg 15kg | 8.5 kg 15kg |
| Cabinet IP Protection | IP65 | IP65 | IP65 | IP65 |
| Brightness (cd/m²) | ≧4000-6000 nit | ≧4000-6000 nit | ≧4000-6000 nit | ≧4000-6000 nit |
| View Angle/° | 160°/140°(H/V) | 160°/140°(H/V) | 160°/140°(H/V) | 160°/140°(H/V) |
| Gray Scale/bit | 14-16 bit | 14-16 bit | 14-16 bit | 14-16 bit |
| Max Power(w/m²) | 800 W/m² | 800 W/m² | 800 W/m² | 800 W/m² |
| Average Power(w/m²) | 240 W/m² | 240 W/m² | 240 W/m² | 240 W/m² |
| Refresh Frequency/Hz | 3840 HZ | 1920/3840 HZ | 1920/3840 HZ | 1920/3840 HZ |
| Operating Voltage | AC 96~242V 50/60Hz | |||
| Operating Temperature | -20~45 °C | |||
| Operatina Humidity | 10~90%R | |||
| Operating Life | 100,000 Hours | |||
Indoor Rental LED Display Parameter
| Pixel Pitch(mm) | 3.91mm | 4.81mm | 2.604mm | 2.976mm |
| LED Spec | SMD2121 | SMD2121 | SMD1515 | SMD1515 |
| Apolication | Indoor | Indoor | Indoor | Indoor |
| Pixel Density(dot/m²) | 65536 dots | 43264 dots | 147456 dots | 112896 dots |
| Module Size/mm | 250×250 | 250×250 | 250×250 | 250×250 |
| Module Resolution | 64X64 dots | 52X52 dots | 96X96 dots | 84X84 dots |
| Module Weigh | 0.5kg | 0.5kg | 0.5kg | 0.5kg |
| Scan | 1/16S | 1/13S | 1/32S | 1/28S |
| Cabinet Size/mm | 500X500mm 500X1000mm | 500X500mm 500X1000mm | 500X500mm 500X1000mm | 500X500mm 500X1000mm |
| Cabinet Resolution | 128×128 dots 128×256 dots | 104×104 dots 104×208 dots | 192×192 dots 192×384 dots | 168x168 dots 168×336 dots |
| Cabinet Weight | 7.5 kg 14kg | 7.5 kg 14kg | 7.5 kg 14kg | 7.5 kg 14kg |
| Cabinet IP Protection | IP24 | IP24 | IP24 | IP24 |
| Brightness (cd/m²) | ≧600-800 nit | ≧600-800 nit | ≧600-800 nit | ≧600-800 nit |
| View Angle/° | 160°/140°(H/V) | 160°/140°(H/V) | 160°/140°(H/V) | 160°/140°(H/V) |
| Gray Scale/bit | 14-16 bit | 14-16 bit | 14-16 bit | 14-16 bit |
| Max Power(w/m²) | 650 W/m² | 650 W/m² | 650 W/m² | 650 W/m² |
| Average Power(w/m²) | 195 W/m² | 195 W/m² | 195 W/m² | 195 W/m² |
| Refresh Frequency/Hz | 1920/3840 HZ | 1920/3840 HZ | 1920/3840 HZ | 1920/3840 HZ |
| Operating Voltage | AC 96~242V 50/61Hz | AC 96~242V 50/62Hz | ||
| Operating Temperature | -20~45 °C | -20~46 °C | ||
| Operatina Humidity | 10~90%RH | 10~90%RH | ||
| Operating Life | 100,000 Hours | 100,001 Hours | ||
FAQ
In which environments are LED displays suitable for use?
LED displays can be used in both indoor and outdoor environments. Indoors, they are commonly used in places such as conference rooms, exhibition halls, and shopping malls. Outdoors, they can be used for billboards, sports venues, stages, and more.
How do I choose the right LED display for my needs?
When choosing an LED display, factors to consider include screen size, resolution, brightness, contrast, viewing angle, protection rating, and more. Additionally, factors such as the application scenario and budget need to be taken into account.
What should I pay attention to when maintaining and caring for LED displays?
To extend the lifespan of LED displays and maintain good display performance, regular maintenance and care are necessary. This includes cleaning the screen surface, checking the connection cables, inspecting the power supply and control system, and more. Additionally, it's important to avoid using LED displays in excessively high or low temperature environments.
